ABB CI858 3BSE018135R1 communication interface module

Original price was: $2,360.00.Current price is: $1,288.00.

ABB CI858 3BSE018135R1 is an industrial communication interface module, specifically designed to enable high-speed data exchange between ABB AC 800M distributed control systems (DCS) and external devices via Profinet IRT protocol, suitable for demanding real-time automation scenarios.

Ayla082209@gmail.com

The price is for reference only. Please contact customer service for the actual price.

Category: ABB

Description

Parameter	Value
Model Number	CI858 3BSE018135R1
Product Type	Profinet IRT Communication Interface Module (for AC 800M DCS)
Power Supply	5V DC (from AC 800M controller backplane)
Current Consumption	0.35 A (typical, at 5V DC)
Power Loss (Heat)	1.75 W (typical)
Communication Protocol	Profinet IRT (Isochronous Real-Time); supports Profinet RT (Real-Time) as fallback
Number of Communication Ports	2 × RJ45 Ethernet ports (Profinet IRT/RT)
Port Speed	10/100/1000 Mbit/s (auto-negotiation, full-duplex)
Max Number of Profinet Devices	Up to 128 Profinet IRT devices per module
Real-Time Cycle Time	Down to 1 ms (for IRT mode)
Isolation	2.5 kVrms (communication ports to backplane, 1 min)
Operating Temperature Range	-25 °C to +70 °C (ambient, when installed in a control cabinet)
Storage Temperature Range	-40 °C to +85 °C
Dimensions (Length × Width × Height)	100 mm × 80 mm × 22 mm (module body, excluding backplane connector)
Weight	0.16 kg (net weight, without packaging)
Compatibility	Designed for ABB AC 800M DCS (compatible with AC 800M controllers with firmware version 5.1 or higher)
Diagnostic Functions	Port link status LED (green = linked, off = no link), IRT synchronization status LED (yellow = synchronized, red = fault), module power LED (green = powered on)
Installation Method	DIN-rail mounting (35mm standard DIN rail, conforming to EN 60715) + backplane connection to AC 800M controller
Protection Level	IP20 (front panel, when installed in a closed, dust-free control cabinet)
Compliance Standards	IEC 61131-2 (industrial control equipment), IEC 61000-6-2 (EMC immunity), IEC 61000-6-3 (EMC emissions), EN 50170 (Profinet compliance)
Operating Humidity Range	5% – 95% (non-condensing, no icing)
MTBF (Mean Time Between Failures)	≥400,000 hours (at 40 °C ambient temperature, per IEC 61709)
Redundancy Support	Optional redundant configuration (when paired with a second CI858 module for Profinet IRT redundancy)
