ABB DO810 3BSE008510R1 Digital Output Module

Original price was: $399.00.Current price is: $118.00.

The ABB DO810 3BSE008510R1 is a digital output module with 16 channels, designed for industrial automation systems. It offers 24V DC current sourcing outputs, with each output channel having a maximum continuous current of 0.5 A, and is well – protected against short – circuits, over – voltage, and over – temperature.

Ayla082209@gmail.com

The price is for reference only. Please contact customer service for the actual price.

Category: ABB Tags: ABB AC 800M, ABB S800 I/O, AC 800M Controllers

Description

Parameter	Details
Model	DO810 3BSE008510R1
Manufacturer	ABB
Product Type	Digital Output Module
Number of Output Channels	16
Output Voltage Range	10 – 30 V DC
Maximum Continuous Output Current per Channel	0.5 A
Channel Grouping	Divided into two isolated groups of 8 channels each
Protection Features	Short – circuit, over – voltage, and over – temperature protection
Voltage Supervision	Each group has a voltage supervision input
Output Components	Each output channel has a short – circuit and over – temperature protected high – side driver, EMC protection components, inductive load suppression, output state indication LED, and optical isolation barrier
Error Signaling	Process voltage supervision input gives channel error signals if voltage disappears, and error signals can be read through the module bus
Current Limiting	Outputs are current – limited to protect against over – temperature; output current is limited when overloaded
Dimensions (Width x Depth x Height)	45 mm x 102 mm x 119 mm (connector included: 45 mm x 111 mm x 119 mm)
Weight	0.15 kg – 0.26 kg (sources vary between these values)
Operating Temperature Range	0°C – +55°C (storage: – 40°C – +70°C)
Humidity	5% – 95% non – condensing
Compatibility with Termination Units	TU810, TU812, TU814, TU830
Mounting	Suitable for standard DIN rail mounting
ROHS Status	Complies with EU directive 2011/65/EU
