ABB KUC711AE101 3BHB004661R0101 Thyristor Gate Control Unit
Original price was: $8,890.00.$6,610.00Current price is: $6,610.00.
The ABB KUC711AE101 (Order No.: 3BHB004661R0101) is a compact thyristor gate control unit, designed to provide precise triggering signals for medium-voltage thyristors in industrial drives and converters, with built-in protection and status monitoring for stable power regulation.
-
-
Ayla082209@gmail.com
The price is for reference only. Please contact customer service for the actual price.
Description
| Parameter | Details |
|---|---|
| Model | KUC711AE101 (Order No.: 3BHB004661R0101) |
| Manufacturer | ABB |
| Product Type | Thyristor Gate Control Unit |
| Core Functions | Precise thyristor triggering signal generation; gate pulse width adjustment; overcurrent/overvoltage protection; real-time status feedback; isolation between control and power circuits |
| Triggering Output | Dual-channel gate signals; pulse width: 10-100 µs (adjustable) |
| Input Control Signal | 4-20 mA DC (control current); 0-10 V DC (auxiliary control voltage) |
| Isolation Voltage | 4 kV RMS (control circuit to power circuit) |
| Operating Frequency Range | 50/60 Hz (line frequency synchronization) |
| Protection Features | Overcurrent protection (trip current: 25 mA DC); overvoltage protection (cutoff voltage: 12 V DC) |
| Status Indicators | 3 LEDs (power on: green; normal operation: blue; fault: red) |
| Power Supply | 24 V DC ±10% |
| Power Consumption | 8 W max |
| Operating Temperature Range | -20°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% – 95% RH (non-condensing) |
| Protection Rating | IP20 (requires installation in NEMA 1/12 enclosures) |
| Dimensions (W × H × D) | 100 mm × 150 mm × 65 mm |
| Weight | 0.3 kg |
| Mounting Type | DIN rail-mounted (35 mm standard rail) |
| Certifications | CE, UL, IEC 60664-1 (insulation coordination) |
| Key Features | Compact design for dense installation; adjustable triggering angle (0-180°); fault self-reset function; anti-interference EMC design |
| System Compatibility | ABB medium-voltage drives (ACS 5000 series); industrial thyristor converters; power regulation systems |
| Applications | Medium-voltage motor speed control; industrial power converters; grid-connected power regulation; traction power supplies; metal processing equipment |
