BENTLY NEVADA 3500/22M 288055-01 data interface module
Original price was: $8,000.00.$5,699.00Current price is: $5,699.00.
BENTLY NEVADA 3500/22M 288055-01 is a high-performance transient data interface module, specifically designed for the 3500 machinery protection and condition monitoring system to collect, store, and transmit transient dynamic data (e.g., vibration waveforms) to host software, enabling real-time equipment fault analysis.
-
-
Ayla082209@gmail.com
The price is for reference only. Please contact customer service for the actual price.
Description
| Parameter | Value |
|---|---|
| Model Number | 3500/22M 288055-01 |
| Product Type | Transient Data Interface Module (for 3500 Monitoring System) |
| Manufacturer | BENTLY NEVADA |
| Power Supply | 5V DC (from 3500 rack backplane) |
| Power Consumption | 8.2 W (typical, at 5V DC) |
| Data Collection Capability | – Transient data: Vibration waveforms, speed fluctuations, and process parameter transients – Sampling rate: Up to 102.4 kS/s per channel (configurable via software) |
| Storage Capacity | Built-in non-volatile memory: 1 GB (for transient data buffering) |
| Communication Interfaces | – 1 × 10/100 Base-TX Ethernet port (RJ45, for data transmission to host software) – 1 × USB-B port (front panel, for local configuration and data retrieval) |
| Compatible Host Software | BENTLY NEVADA System 1® Condition Monitoring Software (v6.0 or higher) |
| Number of Monitored Channels | Supports up to 32 dynamic input channels (when paired with 3500/40M/42M vibration monitors) |
| Isolation | 2.5 kVrms (Ethernet port to backplane, 1 min) |
| Operating Temperature Range | -30 °C to +65 °C (ambient, when installed in 3500 rack) |
| Storage Temperature Range | -40 °C to +85 °C |
| Dimensions (Length × Width × Height) | 241.3 mm × 24.4 mm × 241.8 mm (module body, fits 3500 full-height rack slot) |
| Weight | 0.92 kg (net weight, without packaging) |
| LED Indicators | – OK (green): Module powered on and operating normally – TX/RX (yellow): Ethernet data transmission/reception active – TM (red): Trip multiply mode activated or module fault – Config OK (blue): Valid configuration loaded |
| Rack Slot Requirement | 1 full-height front slot in 3500 rack (must be installed adjacent to 3500 power supply modules) |
| Battery Backup | Internal lithium battery: 38 years service life (powered rack); 12 years service life (unpowered rack) at 50 °C |
| Protection Functions | Overvoltage protection (backplane power input), short-circuit protection (Ethernet port) |
| Compliance Standards | UL 508 (industrial control equipment), ATEX/IECEx Zone 2 (hazardous area certification), CE EMC Directive 2014/30/EU |
| Operating Humidity Range | 5% – 95% (non-condensing, no icing) |
| Seismic Performance | 5-2000 Hz, 15 g acceleration (meets API 670 machinery protection standard) |
| Protection Level | IP20 (when installed in enclosed 3500 rack) |
Reviews (0)
About brand
The BENTLY 3500 system is a professional machinery protection and condition monitoring solution widely used in industries like oil and gas, power generation, and petrochemicals. It adopts a modular design, allowing flexible configuration of monitoring modules (e.g., vibration, temperature, and speed modules) to track key operating parameters of rotating equipment such as turbines and compressors. By collecting and analyzing data in real time, it can promptly identify issues like equipment imbalance or bearing wear, trigger alarms or shutdowns when thresholds are exceeded, and effectively prevent unexpected equipment failures to ensure production continuity.
