ELAU C600/10/1/1/1/00 Multi-axis Motion Controller with Integrated PLC
Original price was: $3,100.00.$2,310.00Current price is: $2,310.00.
ELAU MC-4/11/05/230 Single-Axis Servo Drive
Original price was: $2,690.00.$1,750.00Current price is: $1,750.00.
ELAU C400/10/1/1/1/00 Multi-axis Servo Controller
Original price was: $3,100.00.$2,310.00Current price is: $2,310.00.
The ELAU C400/10/1/1/1/00 is a high-performance multi-axis servo controller from Schneider Electric (formerly ELAU), engineered for precise synchronous motion control with integrated communication and I/O capabilities in demanding industrial automation scenarios.
-
-
Ayla082209@gmail.com
The price is for reference only. Please contact customer service for the actual price.
Description
| Parameter | Details |
|---|---|
| Model | C400/10/1/1/1/1/00 |
| Manufacturer | ELAU (now part of Schneider Electric) |
| Product Type | Multi-axis Servo Controller |
| Rated Continuous Current | 10 A RMS |
| Input Voltage | 3-phase 200-480 V AC (±15%) ; 24 V DC (control circuit) |
| Axis Control Capacity | Up to 16 axes (synchronous control) |
| Synchronization Speed | 2 ms (4 axes); 4 ms (8 axes) |
| Communication Interfaces | Ethernet, CANopen, RS-485 (EtherCAT supported for high-speed transmission) |
| I/O Configuration | 16 digital inputs; 8 digital outputs (24 V DC for both) |
| Dimensions (L x W x H) | 219 mm × 150 mm × 71 mm |
| Weight | 2.1 kg |
| Operating Temperature Range | -20°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% – 95% RH (non-condensing) |
| Protection Rating | IP20 |
| Certifications | CE, UL, cULus, RoHS |
| Key Features | Discrete board TMR (Triple Modular Redundant) architecture; integrated self-test and diagnostics; configurable I/O ports |
| Applications | High-speed packaging machinery, printing presses, textile equipment, and complex multi-axis industrial automation lines |
