FOXBORO FBM207C RH917GY 8-Channel Voltage Monitor & Contact Sense Input Module

Original price was: $2,460.00.Current price is: $1,890.00.

The FOXBORO FBM207C RH917GY is an 8-channel voltage monitor and contact sense input module for Foxboro I/A Series DCS, engineered to accurately acquire 0-10 V DC signals and sense contact status with fast response and robust environmental adaptability.

Ayla082209@gmail.com

The price is for reference only. Please contact customer service for the actual price.

Category: FOXBORO

Description

Parameter	Details
Model	FBM207C (Part No.: RH917GY)
Manufacturer	Foxboro (a Schneider Electric brand)
Product Type	8-Channel Voltage Monitor & Contact Sense Input Module
Input Channels	8 independent input channels
Supported Input Types	0-10 V DC voltage signals; dry/wet contact sense signals
Measurement Range (Voltage)	0-10 V DC
Accuracy	±0.1% of full scale
Response Time	< 1 ms
Channel Isolation	Optically isolated (input to backplane)
Power Supply	24 V DC
Power Consumption	< 3 W (typical for similar FBM modules)
Operating Temperature Range	-40°C to +85°C
Storage Temperature Range	-40°C to +85°C
Relative Humidity	5% – 95% RH (non-condensing)
Dimensions (L x W x H)	162.6 mm × 61.0 mm × 48.3 mm (converted from 6.4″ × 4.8″ × 2.4″)
Weight	0.32 kg
Mounting Type	DIN rail-mountable (compatible with 200-series FBM backplanes)
Certifications	CE, UL
Key Features	Fast signal response; channel-level isolation; LED status indicators; rugged design for harsh environments
System Compatibility	Foxboro I/A Series DCS
Applications	Voltage monitoring in industrial processes; contact status sensing for relays/limit switches; data acquisition in automation systems
