FOXBORO FBM230 P0926GU 8-Channel Isolated Analog Output Module

Original price was: $2,980.00.Current price is: $1,620.00.

The FOXBORO FBM230 P0926GU is an 8-channel analog output module for Foxboro I/A Series DCS, engineered to deliver precise 4-20mA control signals with channel isolation and robust protection features for industrial actuation systems.

Ayla082209@gmail.com

The price is for reference only. Please contact customer service for the actual price.

Category: FOXBORO

Description

Parameter	Details
Model	FBM230 (Part No.: P0926GU)
Manufacturer	Foxboro (a Schneider Electric brand)
Product Type	8-Channel Isolated Analog Output Module
Output Channels	8 independent analog output channels
Output Signal Type	Configurable 4-20mA DC; 0-20mA DC (optional)
Output Resolution	16-bit (D/A conversion)
Output Accuracy	±0.05% of full scale (at 25°C)
Load Capacity	Maximum 500Ω per channel (for 4-20mA)
Update Rate	100ms per channel
Channel Isolation	500V AC (channel-to-channel, channel-to-backplane)
Power Supply	24V DC ±10% (redundant power supported)
Power Consumption	4.5W (maximum)
Operating Temperature Range	-20°C to +70°C
Storage Temperature Range	-40°C to +85°C
Relative Humidity	5% – 95% RH (non-condensing)
Dimensions (L x W x H)	110mm × 45mm × 115mm
Weight	0.38kg
Mounting Type	DIN rail-mountable (compatible with 200-series FBM backplanes)
Certifications	CE, UL 508, ATEX II 3G Ex nA IIC T4, IECEx Ex nA IIC T4
Key Features	Hot-swap capability; short-circuit protection; overcurrent limiting; LED status indicators per channel
System Compatibility	Foxboro I/A Series DCS
Applications	Control of valves, pumps, and actuators in chemical processing, oil & gas, and power generation plants
