FOXBORO FBM233 P0926GX 4-Channel Isolated Analog Output Module

Original price was: $3,850.00.Current price is: $2,600.00.

The FOXBORO FBM233 P0926GX is a 4-channel analog output module for Foxboro I/A Series DCS, designed to convert digital control signals to precise 4-20mA outputs with isolation and diagnostic features for industrial process actuation.

Ayla082209@gmail.com

The price is for reference only. Please contact customer service for the actual price.

Category: FOXBORO

Description

Parameter	Details
Model	FBM233 (Part No.: P0926GX)
Manufacturer	Foxboro (a Schneider Electric brand)
Product Type	4-Channel Isolated Analog Output Module
Output Channels	4 independent analog output channels
Output Signal Type	Configurable 4-20mA DC (default); 0-20mA DC (optional)
Output Resolution	16-bit (D/A conversion)
Output Accuracy	±0.05% of full scale (at 25°C)
Load Capacity	Maximum 750Ω per channel (for 4-20mA)
Update Rate	100ms per channel
Channel Isolation	1500V AC (channel-to-channel, channel-to-backplane)
Power Supply	24V DC ±10% (redundant power supported)
Power Consumption	4W (maximum)
Operating Temperature Range	-20°C to +70°C
Storage Temperature Range	-40°C to +85°C
Relative Humidity	5% – 95% RH (non-condensing)
Dimensions (L x W x H)	110mm × 45mm × 115mm
Weight	0.35kg
Mounting Type	DIN rail-mountable (compatible with 200-series FBM backplanes)
Certifications	CE, UL 508, ATEX II 3G Ex nA IIC T4, IECEx Ex nA IIC T4
Key Features	Hot-swap capability; short-circuit protection; overcurrent limiting; LED status indicators per channel
System Compatibility	Foxboro I/A Series DCS
Applications	Control of valves, dampers, and variable speed drives in oil & gas, chemical processing, and power generation facilities
