FOXBORO FCP280 RH924YA Field Control Processor

Original price was: $5,398.00.Current price is: $4,120.00.

The FOXBORO FCP280 RH924YA is a high-performance field control processor for Foxboro I/A Series DCS, designed to execute complex control strategies with redundant architecture for reliable industrial process automation.

Ayla082209@gmail.com

The price is for reference only. Please contact customer service for the actual price.

Category: FOXBORO

Description

Parameter	Details
Model	FOXBORO FCP280 RH924YA
Manufacturer	Foxboro (a Schneider Electric brand)
Product Type	Field Control Processor (for I/A Series DCS)
Processing Power	32-bit RISC processor, 1 GHz clock speed
Memory	2 GB RAM; 4 GB flash storage
Control Execution Rate	Configurable down to 10 ms
I/O Capacity	Supports up to 4096 I/O points
Redundancy	1:1 hot standby (automatic switchover < 50 ms)
Communication Interfaces	2 x Ethernet (10/100/1000 Mbps); 2 x serial ports (RS-232/485)
Protocols Supported	Modbus TCP/IP, OPC UA, DNP3, Ethernet/IP
Power Supply	24 V DC ±10% (redundant input); 100-240 V AC (optional)
Power Consumption	25 W (typical); 35 W (maximum)
Operating Temperature Range	0°C to 55°C
Storage Temperature Range	-40°C to 70°C
Relative Humidity	5% – 95% RH (non-condensing)
Dimensions (L x W x H)	220 mm × 160 mm × 80 mm
Weight	1.8 kg
Mounting Type	19-inch rack mount (1U height)
Certifications	CE, UL 61010-1, ATEX, IECEx
Key Features	Fault-tolerant design; embedded diagnostics; remote configuration; secure firmware updates
System Compatibility	Foxboro I/A Series DCS (V9.0 and later)
Applications	Centralized control for oil & gas, chemical processing, power generation, and water/wastewater treatment plants
