HIMA Z7138 8-Channel Failsafe Digital Output Module
Original price was: $1,190.00.$910.00Current price is: $910.00.
The HIMA Z7138 is a failsafe 8-channel digital output module for safety-critical systems, engineered to control 24V DC industrial devices with short-circuit protection and SIL compliance for high-reliability applications.
-
-
Ayla082209@gmail.com
The price is for reference only. Please contact customer service for the actual price.
Description
| Parameter | Details |
|---|---|
| Model | Z7138 |
| Manufacturer | HIMA |
| Product Type | 8-Channel Failsafe Digital Output Module |
| Output Channels | 8 independent digital output channels |
| Output Signal Type | Active two-wire; 24 V DC |
| Output Current | 1.2 A per channel |
| Load Compatibility | Resistive, inductive loads |
| Power Supply | 20.4 V DC to 31.2 V DC |
| Power Consumption | 100 mA |
| Protection Features | Short-circuit protection; under-voltage tripping; safe isolation |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% – 95% RH (non-condensing) |
| Dimensions (L x W x H) | 120 mm × 100 mm × 22.5 mm |
| Weight | 0.2 kg |
| Mounting Type | DIN rail-mountable (compatible with HIMA safety system chassis) |
| Certifications | CE, UL, ATEX |
| Key Features | Failsafe design; self-testing functionality; compact form factor; hot-swap capable |
| System Compatibility | HIMA safety instrumented systems (SIS) for critical control loops |
| Applications | Emergency shutdown systems (ESD), fire & gas detection, and valve/actuator control in oil & gas, chemical, and power industries |
Reviews (0)
About brand
HIMA (HIMA Paul Hildebrandt GmbH) was founded in 1908 and is headquartered in Mannheim, Germany. It is a family owned enterprise with over a hundred years of history, focusing on industrial safety automation solutions and enjoying a global leading position in the process industry and rail transit fields. Its name is derived from the founder's surname "Hildebrandt" and the abbreviation of its location "Mannheim", reflecting family inheritance and regional origins.
