TRICONEX 3007 SIS Processor Module
Original price was: $3,980.00.$2,288.00Current price is: $2,288.00.
The TRICONEX 3007 is a high-reliability processor module designed for the Triconex safety instrumented system (SIS), leveraging triple modular redundant (TMR) architecture to ensure fault tolerance and continuous operation in safety-critical industrial applications.
-
-
Ayla082209@gmail.com
The price is for reference only. Please contact customer service for the actual price.
Description
| Parameter | Details |
|---|---|
| Model | 3007 |
| Manufacturer | TRICONEX |
| Product Type | SIS Processor Module |
| Processor Type | 32-bit RISC processor (triple-core for TMR redundancy) |
| Clock Speed | 166 MHz |
| Memory Capacity | 16 MB Flash memory (for program storage); 8 MB SRAM (for data processing) |
| Supported I/O Capacity | Up to 1,024 I/O points (when paired with compatible I/O modules) |
| Communication Interfaces | 2 x RS-232 ports (for programming/debugging); 1 x Ethernet port (10/100 Mbps, for system integration) |
| Power Supply Requirement | 5 VDC (from chassis power module); Current draw: 1.2 A (max) |
| Power Consumption | 6 W (typical); 7.2 W (max) |
| Operating Temperature Range | -40 °C to +70 °C (-40 °F to +158 °F) |
| Storage Temperature Range | -55 °C to +85 °C (-67 °F to +185 °F) |
| Humidity | 5% – 95% RH (non-condensing, at 40 °C) |
| Dimensions (L x W x H) | 228 mm x 165 mm x 38 mm (9.0 in x 6.5 in x 1.5 in) |
| Weight | 0.85 kg (1.87 lbs) |
| Redundancy Architecture | Triple Modular Redundant (TMR) – 3 independent processing cores with majority voting |
| Safety Certification | IEC 61508 SIL 3; ATEX II 3G Ex nA IIC T4 Ga; IECEx Ex nA IIC T4 Ga |
| Diagnostic Coverage | 99.9% (for critical faults) |
| Mounting Compatibility | TRICONEX 8100/8110 series main chassis (3U rack slot) |
| Status Indicators | 6 LEDs: Power (green), Run (green), Fault (red), TMR Sync (yellow), Communication (green), Ready (blue) |
| Applications | Safety instrumented systems (SIS), emergency shutdown (ESD), fire & gas (F&G) systems in oil & gas, petrochemical, power generation, and chemical industries |
